Suzuki DF 90A Parts Listings - 2024
S/N 09003F-440001 to 09003F-44XXXX
Fig. 113 - Cylinder Block
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 11291-87L10 HOOK,ENGINE
SKU: 11291-87L10 Weight: 0.000000 Brand: Price: $ 6.99 |
HOOK,ENGINE | 1 | $ 6.99 | ||
| 2 | 01550-0820C BOLT
SKU: 01550-0820C Weight: 0.060000 Brand: Price: $ 1.94 |
BOLT | 2 | $ 1.94 | ||
| 3 | 11300-87L20 BLOCK ASSY,CYLI
SKU: 11300-87L20 Weight: 0.000000 Brand: Price: $ 1,852.30 |
BLOCK ASSY,CYLI | 1 | $ 1,852.30 | ||
| 4 | 11117-90J10 Crankcase Bolt
SKU: 11117-90J10 Weight: 0.250000 Brand: Price: $ 7.01 |
Crankcase Bolt | 10 | $ 7.01 | ||
| 5 | 11216-90J10 Oil Gallery Plug Gasket
SKU: 11216-90J10 Weight: 0.060000 Brand: Price: $ 3.39 |
Oil Gallery Plug Gasket | 3 | $ 3.39 | ||
| 6 | 09248-18014 Plug (18x8)
SKU: 09248-18014 Weight: 0.200000 Brand: Price: $ 6.47 |
Plug (18x8) | 3 | $ 6.47 | ||
| 7 | 11118-98J02 PLUG
SKU: 11118-98J02 Weight: 0.000000 Brand: Price: $ 3.09 |
PLUG | 1 | $ 3.09 | ||
| 8 | 09206-13019 Knock Pin
SKU: 09206-13019 Weight: 0.062500 Brand: Price: $ 2.93 |
Knock Pin | 5 | $ 2.93 | ||
| 9 | 01550-08407 BOLT 8 X 40
SKU: 01550-08407 Weight: 0.060000 Brand: Price: $ 4.02 |
BOLT 8 X 40 | 10 | $ 4.02 | ||
| 10 | 09401-15414 Clip
SKU: 09401-15414 Weight: 0.062500 Brand: Price: $ 2.71 |
Clip | 1 | $ 2.71 | ||
| 12 | 01550-0612C BOLT
SKU: 01550-0612C Weight: 0.060000 Brand: Price: $ 2.00 |
BOLT | 2 | $ 2.00 | ||
| 13 | 11224-87L00 Breather Hose No. 2 (NLA)
SKU: 11224-87L00 Weight: 0.250000 Brand: Price: $ 8.11 |
Breather Hose No. 2 (NLA) | 1 | $ 8.11 | ||
| 14 | 11294-87L00 BRACKET,ENGINE
SKU: 11294-87L00 Weight: 0.000000 Brand: Price: $ 22.81 |
BRACKET,ENGINE | 1 | $ 22.81 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
